Double orifice ram BOP

Description

>>Double orifice ram BOP Product features： Structural style：Shaffer style,Cameron style Two kinds of locking systen could be chosen:the manual locking system and the automatic hydaulic locking system Not only the pipe rams and blind rams but aslo the variable bore rams and shear rams are available without any structure change It is easy and convenient on-site to open the bonners by hydraulic pressure The outlets on the both sides of the body make the operation on site flexible The pressurized self-sealing sealing mechanism is used between the body and bonnets,so it is not necessary to apply too much pretightening force to secure the reliability of sealing It is very convenient to lift and transport the BOPs with the four lifting rods The new sealing mechanism of ram shaft secures the sealing reliability under the high pressure The ring grooves of flanges are all lined with the corrosion resistant alloy Matched-manufacturing is not necessary for the bonnets and body,so the diserepancy could be eliminated by thestructure.And it is convenient for the maintenance in the future According to the latest API Spec 16A standard According to the latest API Spec Q1 , quality standard of IOS9001 and NACE-MR-01-75 ,H2st Trim According to user requirements and the use of environmental can choose casting or forging. >>Product type and specification：

Item	Type	Specification
1	7-1/16″-3000psi Single ram BOP/Double ram BOP	Bore: 7-1/16″ Working pressure: 3,000psi Top connection: 7-1/16″-3000psi 6B R45 SST Studded Bottom connection: 7-1/16″-3000psi 6B R45 SST Flanged
2	7-1/16″-5000psi Single ram BOP/Double ram BOP	Bore: 7-1/16″ Working pressure: 5,000psi Top connection: 7 1/16″-5000psi 6B R46 SST Studded Bottom connection: 7 1/16″-5000psi 6B R46 SST Flanged
3	7-1/16″-10000psi Single ram BOP/Double ram BOP	Bore: 7-1/16″ Working pressure: 10000psi Top connection: 7 1/16″-10000psi 6BX BX156 SST Studded Bottom connection: 7 1/16″-10000psi 6BX BX156 SST Flanged
4	7-1/16″-15000psi Single ram BOP/Double ram BOP	Bore: 7-1/16″ Working pressure: 15,000psi Top connection: 7 1/16″-15000psi 6BX BX156 SST Studded Bottom connection: 7 1/16″-15000psi 6BX BX156 SST Flanged
5	9″-3000psi Single ram BOP/Double ram BOP	Bore: 9″ Working pressure: 3,000psi Top connection: 9″-3000psi 6B R49 SST Studded Bottom connection: 9″-3000psi 6B R49 SST Flanged
6	9″-5000psi Single ram BOP/Double ram BOP	Bore: 9″ Working pressure: 5,000psi Top connection: 9″-5000psi 6B R50 SST Studded Bottom connection: 9″-5000psi 6B R50 SST Flanged
7	9″-10000psi Single ram BOP/Double ram BOP	Bore: 9″ Working pressure: 10,000psi Top connection: 9-″10000psi 6BX BX157 SST Studded Bottom connection: 9″-10000psi 6BX BX157 SST Flanged
8.	11″-3000psi Single ram BOP/Double ram BOP	Bore: 11″ Working pressure: 3,000psi Top connection: 11″-3000psi 6B R53 SST Studded Bottom connection: 11″-3000psi 6B R53 SST Flanged
9	11″-5000psi Single ram BOP/Double ram BOP	Bore: 11″ Working pressure: 5,000psi Top connection: 11″-5000psi 6B R54 SST Studded Bottom connection: 11″-5000psi 6B R54 SST Flanged
10	11″-10000psi Single ram BOP/Double ram BOP	Bore: 11″ Working pressure: 10,000psi Top connection: 11″-10000psi 6BX BX158 SST Studded Bottom connection: 11″-10000psi 6BX BX158 SST Flanged
11	11″-15000psi Single ram BOP/Double ram BOP	Bore: 11″ Working pressure: 15,000psi Top connection: 11″-15000psi 6BX BX158 SST Studded Bottom connection: 11”-15000psi 6BX BX158 SST Flanged
12	13-5/8″-3000psi Single ram BOP/Double ram BOP	Bore: 13 5/8″ Working pressure: 3,000psi Top connection: 13 5/8″-3000psi 6B R57 SST Studded Bottom connection: 13 5/8″-3000psi 6B R57 SST Flanged
13	13-5/8″-5000psi Single ram BOP/Double ram BOP	Bore: 13 5/8″ Working pressure: 5,000psi Top connection: 13 5/8″-5000psi 6BX BX160 SST Studded Bottom connection: 13 5/8″-5000psi 6BX BX160 SST Flanged
14	13-5/8″-10000psi Single ram BOP/Double ram BOP	Bore: 13 5/8″ Working pressure: 10,000psi Top connection: 13 5/8″-10000psi 6BX BX159 SST Studded Bottom connection: 13 5/8″-10000psi 6BX BX159 SST Flanged
15	13-5/8″-15000psi Single ram BOP/Double ram BOP	Bore: 13 5/8″ Working pressure: 15,000psi Top connection:13 5/8″-15000psi 6BX BX159 SST Studded Bottom connection:13 5/8″-15000psi 6BX BX159 SST Flanged
16	16-3/4″-5000psi Single ram BOP/Double ram BOP	Bore: 16 3/4″ Working pressure: 5,000psi Top connection: 16 3/4″-5000psi 6BX BX162 SST Studded Bottom connection: 16 3/4″-5000psi 6BX BX162 SST Flanged
17	16-3/4″-10000psi Single ram BOP/Double ram BOP	Bore: 16 3/4″ Working pressure: 10,000psi Top connection: 16 3/4″-10000psi 6BX BX162 SST Studded Bottom connection: 16 3/4″-10000psi 6BX BX162 SST Flanged
18	18-3/4″-5000psi Single ram BOP/Double ram BOP	Bore: 18 3/4″ Working pressure: 5,000psi Top connection: 18 3/4″-5000psi 6BX BX163 SST Studded Bottom connection: 18 3/4″-5000psi 6BX BX163 SST Flanged
19	18-3/4″-10000psi Single ram BOP/Double ram BOP	Bore: 18 3/4″ Working pressure: 10,000psi Top connection: 18 3/4″-10000psi 6BX BX164 SST Studded Bottom connection: 18 3/4″-10000psi 6BX BX164 SST Flanged
20	18-3/4″-15000psi Single ram BOP/Double ram BOP	Bore: 18 3/4″ Working pressure: 15,000psi Top connection: 18 3/4″-15000psi 6BX BX164 SST Studded Bottom connection: 18 3/4″-15000psi 6BX BX164 SST Flanged
21	20-3/4″-3000psi Single ram BOP/Double ram BOP	Bore: 20 3/4″ Working pressure: 3,000psi Top connection: 20 3/4″-3000psi 6B R74 SST Studded Bottom connection: 20 3/4″-3000psi 6B R74 SST Flanged
22	21-1/4″-2000psi Single ram BOP/Double ram BOP	Bore: 21 1/4″ Working pressure: 2,000psi Top connection: 21 1/4″-2000psi 6B R73 SST Studded Bottom connection: 21 1/4″-2000psi 6B R73 SST Flanged
23	21-1/4″-5000psi Single ram BOP/Double ram BOP	Bore: 21 1/4″ Working pressure: 5,000psi Top connection: 21 1/4″-5000psi 6B BX165 SST Studded Bottom connection: 21 1/4″-5000psi 6B BX165 SST Flanged
24	21-1/4″-10000psi Single ram BOP/Double ram BOP	Bore: 21 1/4″ Working pressure: 10,000psi Top connection: 21 1/4″-10000psi 6B BX166 SST Studded Bottom connection: 21 1/4″-10000psi 6B BX166 SST Flanged
25	26-3/4″-2000psi Single ram BOP/Double ram BOP	Bore: 26 3/4″ Working pressure: 2,000psi Top connection: 26 3/4″-2000psi 6B BX167 SST Studded Bottom connection: 26 3/4″-2000psi 6B BX167 SST Flanged
26	26-3/4″-3000psi Single ram BOP/Double ram BOP	Bore: 26 3/4″ Working pressure: 3,000psi Top connection: 26 3/4″-3000psi 6B BX168 SST Studded Bottom connection: 26 3/4″-3000psi 6B BX168 SST Flanged
